Architecture

structure

plan detials

What it's include:


  • ​Cover Sheet: Shows the front elevation and typical notes and requirements.

  • Structural Calculation Report: This report encloses the following information:

    •  Structural Analysis. Construction requirements are as per specific building codes considering the project type.

    • Seismic Analysis following procedures in Codes IBC 2003 & ASCE 7-02.

      • Spectral response accelerations according to the Probabilistic Seismic Hazard Assessment for the Eastern Caribbean Islands (The University of West Indies/ Seismic Research Center).

    • Wind Load Analysis.

    • Design Considerations for Foundations.

    • Design Considerations for Structural Elements (Walls, Slabs, Columns, Beams)

    • Dimensions of footings according to allowable bearing pressure.

    • Slab and stairs design analysis.

    • Walls calculation analysis.

    • Beams calculation analysis. General views, bending moments, etc.

    • Retaining walls analysis and dimensioning.

    • Others according to the structure and project type.

  • Structural Construction Blueprints Includes:

  • Layouts: Shows the structural details for construction, material requirements, dimensions, and specifications for foundations, floor plans, and roof plans

  • Section and Details: Shows cross sections and necessary construction details and specifications, steel schedules, steel shapes, and steel connection details. General and specific structural construction roof details.

  • Wood structural details and specifications.

  • Other necessary details are to be specified per the structure type and project.

  • Typical wall section and details

  • Typical Stair section and details

  • Structural Engineering Credentials.

​

Consulting

EEC offers diverse structural consulting services, from basic to complex.

  • Initial Consultation: Understanding our client's ideas and requirements and narrowing the scope.

  • Conceptual Design: Our team develops preliminary design concepts in close coordination with architectural designs.

  • EEC offers customized design services for structures that cater to the specific requirements of each project. Our designs are innovative and creative, built with the latest codes, standards, and technologies.

  • Our Engineers use advanced software tools to analyze and simulate optimal structural behavior under specific load combinations and environmental conditions, ensuring optimal performance and reliability.

  • By closely collaborating with architects, contractors, and other stakeholders, we develop cost-effective solutions that align with the project's objectives.

  • With our knowledge of structural dynamics, earthquake engineering, and finite element analysis, we create secure and long-lasting designs.

  • Our team provides construction blueprints and documentation.

  • Supervision: During the construction, our team ensures the execution according to the approved construction blueprints and specifications.

  • Structural Pathologies: Our team offers comprehensive evaluations of structures to identify defects and failures and provide diagnoses with recommendations for demolition, restoration, or renovation projects.

sample structural blueprints

Structure

PLUMBING


plan detials

What it's include:


  • ​Cover Sheet: Shows Front Elevation, notes, and general construction requirements.

  • Hydraulic Report. Provide details and descriptions of the following aspects:

    • General description of the project.
    • Project site conveyance features (canals, channels, basins, structures, etc.)
    • Model configurations.
    • Model assumptions.
    • Model parameters.
    • Model calibration procedures.
    • Copies of the source material including input and output if revising an existing model.
    • Tabulated results for different analyses performed.
    • Conclusions and principal recommendations for construction procedures.

  • Construction Blueprints Includes:

  • Layouts: Shows the plumbing layout details (piping, fixtures, appurtenances, equipment, etc.) Dimensioning, details, and specifications for construction.

  • Section and Details: Shows cross sections, construction details and specifications, piping and fixtures rescheduled.

  • Other necessary details are to be specified per the type and project.

  • Riser Diagrams: Shows isometric views (partial and integral) for all the piping systems and equipment installations.

  • Hydraulic Engineering Credentials.

​

Consulting

EEC offers diverse plumbing consulting services, from basic to complex.

  • Initial Consultation: Understanding our client's ideas and requirements and narrowing the scope.

  • Plumbing System and Piping Layout and Schematic design.

  • Feasibility and Predesign Studies.

  • Swimming Pool Systems. Planning and Design.

  • Storm Drain Planning and Design.

  • Natural gas piping planning and design.

  • Drainage System Planning and Design.

  • Domestic Water System Planning and Design.

  • Water Heater System Design and Specifications.

  • Firefighting System Planning and Design.

  • Sanitary/Sewer (Wastewater) System Planning and Design.

  • Industrial Steam Piping Planning and Design.

  • Roof Drain and Storm Water Planning and Design.

  • Our professionals use advanced software tools for modeling water systems and conveyance structures. â€‹

sample PLUMBING blueprints

Plumbing

ELECTRICAL

plan detials

What it's include:


  • ​Cover Sheet: Shows the following information:

    • Typical Grounding Schematic​

    • Electrical Riser Diagram.

    • General Notes​

  • Construction Blueprints Includes:

  • Lighting Plans: Shows the lighting layout details (fixtures, wiring, control panel locations, etc.) Dimensioning, details, and specifications for construction.

  • Power Plan: Shows receptacles, Electrical Meter, Electrical Panel, Switches location, Wiring, Piping, Electrical Fixtures.

  • Power Supply Plan: Shows Main Panels and Circuits.

  • Panel Schedule: Shows Panel Schedule with the following information:

    • Load Served.​

    • Conduits sizes.

    • Wire Gauge.

    • Type

    • Trip

    • Phase

    • Circuit

    • Demand Load Calculation.

  • Electrical Report. Provide details and descriptions of the following aspects:

    • General description of the project.
    • Descriptive report memos
    • Model configurations.
    • Model assumptions.
    • Model parameters.
    • Model calibration and procedures.
    • Tabulated results for different analyses performed.
    • Conclusions and principal recommendations for construction procedures.
  • Electrical Engineering Credentials

​

Consulting

EEC offers diverse plumbing consulting services, from basic to complex.

  • Initial Consultation: Understanding our client's ideas and requirements and narrowing the scope.

  • Lighting System Planning and Design

    • We specialize in creating lighting systems that optimize illumination while considering energy efficiency and visual comfort.

  • Power Distribution

    •  Our expertise encompasses the planning and design of power distribution systems, ensuring efficient and reliable electricity supply.

  • Clean Energy Solutions

    •  Integrating renewable energy sources to promote sustainability and reduce environmental impact.

  • Electrical Safety and Code Compliance

    • Ensuring that all electrical systems comply with safety standards and local building codes.

  • Fire Alarm and Detection Systems

    •  Designing systems to ensure early detection and prompt response to fire emergencies.

  • Emergency and Standby Power Systems

    •  Designing systems to provide emergency power during unforeseen outages, enhancing safety and continuity.

  • Hospital and Medical Facility Power Systems

    •  Providing specialized power solutions for critical medical equipment and facilities.

  • Renewable Energy Systems Integration

    • Incorporating renewable energy solutions to promote environmentally friendly practices.

  • Data Center Electrical Systems

    •  Designing electrical systems for data centers to ensure uninterrupted operation.

  • Our professionals use advanced software tools for modeling.

    • Leveraging cutting-edge CAD and Revit software, our engineers create detailed design drawings to guide construction workers and building managers through the intricacies of a building’s electrical system.

sample ELECTRICAL blueprints

Electrical

HVAC

Air Compressor
Air Filter
Repairing Air Conditioner
Room Temperature

plan detials

What it's include:


  • ​Cover Sheet: Shows the following information:

    • Typical Grounding Schematic​

    • Electrical Riser Diagram.

    • General Notes​

​

Construction Blueprints Includes:

​

  • Floor Plans: Detailed floor plans showing the layout of the air conditioning system, including ductwork routes, air handling units (AHUs), evaporators, condensers, and ventilation equipment.

​

  • Ductwork Diagrams: Showing detailed routes of the duct system and airflow paths, specifying materials, sizes, and any necessary insulation.

​

  • Equipment Placement: Indicating locations for indoor units, outdoor units, air handling units, and any other HVAC equipment.

​

  • Piping and Drainage: Diagrams for refrigerant piping, condensate drainage systems, and water circulation systems if applicable.

​

  • HVAC Zones: The building is divided into temperature zones, with specific systems designed to meet the needs of each zone.

​

  • MEP Credentials

​

Consulting

Air conditioning design consultancy services are specialized in developing systems that provide effective heating, cooling, and ventilation for residential, commercial, and industrial spaces. The process involves detailed blueprints and considerations to ensure energy efficiency, comfort, and compliance with building codes.

The consultancy services include:


  • Cooling and Heating Load Calculations:
    Determining the required heating and cooling capacity for the space, considering factors like building size, orientation, insulation, occupancy, heat sources (equipment, lighting, etc.), and outdoor climate.


  • Air Distribution: Designing the air distribution system, including ductwork, vents, and diffusers to ensure proper airflow throughout the building. This includes selecting appropriate materials, sizes, and configurations for air ducts.


  • Energy Efficiency: Designing systems that maximize energy efficiency through features such as variable refrigerant flow (VRF), zoning systems, or heat recovery systems.


  • Equipment Selection: Choosing appropriate air conditioning units (e.g., split systems, packaged units, chillers) based on system capacity, efficiency, and other design parameters.


  • Control Systems: Incorporating control systems like thermostats, programmable controllers, and advanced building management systems (BMS) to optimize temperature regulation.

sample hvac blueprints

HVAC

ARCHITECTURE

plan detials

What it's include:


  • ​Cover Sheet: Shows the front elevation and typical notes and requirements.

  • Exterior Elevations: Shows the front, rear, and sides of the home, including exterior materials, details, and measurements.

  • Section and Details: Shows cross sections and necessary construction details and specifications.

  • Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.

  • Electrical Plans: Shows the location of outlets, fixtures, and switches. They are shown as separate sheets to make the floor plans more legible.

  • Foundation Plans will include a basement, crawlspace, or slab depending on what is available for the home plan.

  • Reflecting Ceiling Plans: Shows the ceiling plans, installation heights, material, and construction details specifications.

  • Roof Plan: Show a roof layout, shapes, slopes, and type of roof with material details and specifications.

  • Typical wall section

  • Typical Stair section

  • Cabinets are shown on all plans.

  • Furniture and appliances layout

  • Additional as requested: Renderings & Animations.

  • Architecture Credentials.

​

Consulting

EEC offers diverse architectural consulting services, from basic to complex.

  • Engage with clients to understand their problems and requirements.

  • Supports clients with issues related to the design and construction of buildings. Including:

    • Reviewing Building Plans. ​

    • Offering Design Advice.

    • Providing Support in Ongoing Construction.

  • Reviewing the building and remodeling plans and suggesting changes that could improve the design.

  • Offer guidance on materials, colors, and textures that would be compatible with the home style.

  • Assess potential problems with designs and provide recommendations.

  • Overseeing construction ensuring that the construction is according to the plans.

  • Inspect finished products to guarantee they meet the regulations of local codes and esthetic standards.

  • Produce the "As Built" set of drawings after the project completion.

  • Support clients to obtain construction permits from local regulators in St. Kitts and Nevis.

sample arch blueprints
